| Model | EZ-168FC | EZ-168FC-1 | EZ-170FC | EZ-188FC | EZ-190FC | EZ-192FC |
| Max output | 5.5HP | 6.5HP | 7HP | 13HP | 15HP
| 17HP |
| Type | Forced air coling,4-stroke OHV,single cylinder,inclined by 25 degree |
| Rated power | 3.6kW/3600rpm | 4.1kW/3600rpm | 5kW/3600rpm | 8.2kW/3600rpm | 9kW/3600rpm | 11.2kW/3600rpm |
| Fuel tank capacity | 3.6L
| 3.6L | 3.6L | 6.5L | 6.5L | 6.5L |
| Fuel consumpotion | ≤395g/kW.h | ≤395g/kW.h | ≤395g/kW.h | ≤395g/kW.h | ≤395g/kW.h | ≤395g/kW.h |
| Oil capacity | 0.6L | 0.6L | 0.6L | 1.1L | 1.1L | 1.1L |
| Oil Consumption | ≤6.8g/kW.h | ≤6.8g/kW.h | ≤6.8g/kW.h | ≤6.8g/kW.h | ≤6.8g/kW.h | ≤6.8g/kW.h |
| Min.Stable Speed Unloaded | 1800rpm |
| Transmission Mode | Chain Mode
|
| Reduction Ration | 2:1 | 2:1 | 2:1 | 2:1 | 2:1 | 2:1 |
| Bore×Stroke | 68×45mm | 68×54mm | 70×55mm | 88×64mm | 90×66mm | 92×66mm |
| Displacement | 163cc | 196cc | 212cc | 389cc | 420cc | 440cc |
| Compression | 8.5:1 | 8.5:1 | 8.5:1 | 8.0:1 | 8.3:1 | 8.3:1 |
| Starting System | Recoil Start/Electric Start |
| lgnition System | Transisterized Magnto lgnition |
| N.W/G.W | 14.5kgs/15.5kgs | 15kgs/16kgs | 15.5kgs/16.5kgs | 34kgs/35kgs | 34kgs/35kgs | 34kgs/35kgs |
| CTN Size | 400×330×340mm | 400×330×340mm | 400×330×340mm | 475×460×520mm | 475×460×520mm | 475×460×520mm |
| Loading | 1400pcs/40HQ | 1400pcs/40HQ | 1400pcs/40HQ | 570pcs/40HQ | 570pcs/40HQ | 570pcs/40HQ |
