Product Center

GASOLINE WATER PUMP

Product Description

Modle	WP-15(40-5)	WP-15(40-6)	WP-15(139F)	WP-15(GX35)	WP-15(152F)
Engine Type	Single-cylinder,2-stroke,Air-cooled		Single-cylinder,4-stroke,Air-cooled		Single-cylinder,4-stroke,Air-cooled,OHV
Engine Model	1E40F-5	1E40F-6	139F	GX35	152F
Displacemment	42.7cc	40.2cc	31cc	35.8cc	98cc
Speed	6500rpm	6500rpm	6500rpm	6500rpm	3600rpm
Rated output power	1.3KW	1.4KW	0.8KW	0.95KW	2.5HP
Starting system	Recoil
Fuel mixture ratio	Gasoline:Tow-cycleOil(25:1)		/	/	/
Fuel TankCapacity	1.2L	1.2L	0.7L	0.63L	1.3L
Oil Tank Capacity	/	/	0.08L	0.1L	0.36L
Diameter of outlet/inlet	40mm(1.5")	40mm(1.5")	40mm(1.5")	40mm(1.5")	40mm(1.5")
Flow	7.5m³/h	7.5m³/h	6.5m³/h	6.5m³/h	12m³/h
Suction head	8m	8m	8m	8m	5m
Pump Lift	28m	28m	28m	28m	10m
N.W./G.W.	7.5kgs/8.5kgs	7.5kgs/8.5kgs	7.5kgs/8.5kgs	7.5kgs/8.5kgs	12kgs/13kgs
CTN Size	400×305×350mm	400×305×350mm	400×305×350mm	400×305×350mm	360×300×375mm
Loading	700pcs/20GP	700pcs/20GP	700pcs/20GP	700pcs/20GP	680pcs/20GP
